Recommended Torque Values

Model	Trim	Years	Torque
3000GT	VR4 COUPE	1991 - 1999	100 ft.-lbs.
CORDIA	L/LS	1985 - 1988	80 ft.-lbs.
DIAMANTE	SEDAN	1992 - 2004	80 ft.-lbs.
ECLIPSE	BASE	1990 - 1999	100 ft.-lbs.
ECLIPSE	GS	2000 - 2012	80 ft.-lbs.
ECLIPSE SPYDER	17-INCH / GS/GT	2007 - 2012	80 ft.-lbs.
ENDEAVOR	17-INCH	2004 - 2011	80 ft.-lbs.
EXPO	ALL	1992 - 1995	80 ft.-lbs.
GALANT	14" BASE	1985 - 2012	80 ft.-lbs.
I-MIEV	15"BASE / ES	2018 - 2018	See the owner's manual
I-MIEV	15"BASE / ES/SE	2012 - 2016	80 ft.-lbs.
LANCER	SEDAN / ES	2002 - 2018	80 ft.-lbs.
LANCER SPORTBCK	18"BASE / GTS	2010 - 2014	80 ft.-lbs.
MIRAGE	14"BASE / ES	2018 - 2018	See the owner's manual
MIRAGE	BASE/L/M	1985 - 2018	80 ft.-lbs.
MONTERO	ALL	1985 - 2006	85 ft.-lbs.
MONTERO	15" BASE / LS/RS/SR	1995 - 1999	90 ft.-lbs.
MONTERO SPORT	15" BASE / ES	2001 - 2004	85 ft.-lbs.
OUTLANDER	2WD / LS/XLS	2003 - 2016	80 ft.-lbs.
OUTLANDER SPORT	16"BASE / ES	2011 - 2016	80 ft.-lbs.
PICK-UP	4WD	1988 - 1995	100 ft.-lbs.
PRECIS	BASE/LS/RS	1987 - 1994	70 ft.-lbs.
RAIDER	ALL CABS / 265/70R16	2006 - 2009	135 ft.-lbs.
SIGMA	V6	1989 - 1990	80 ft.-lbs.
STARION	2/DOOR / ES	1983 - 1989	80 ft.-lbs.
TREDIA	ALL	1984 - 1988	80 ft.-lbs.
VAN/WAGON	ALL	1987 - 1990	100 ft.-lbs.

Ensuring Safety: Mitsubishi's Lug Nuts

In order to maintain the integrity of your wheels and overall vehicle safety, you should make sure that your Mitsubishi's lug nuts are secure. Here are some tips on how to do this:

• 1. The lug nuts should always be tightened to the manufacturer's specified torque as over tightening can strip the threads or warp the brake rotor, and under tightening can cause the wheel to fall off.
• 2. Use a torque wrench: Torque wrenches ensure the correct amount of force is applied. Avoid using impact wrenches for final tightening.
• 3. Make sure the lug nuts are tight after a wheel change or tire rotation, especially after driving a few miles.
• 4. Make sure the threads on the lug nuts and wheel studs are clean and free from debris. Rust and dirt can interfere with the tightening and seating of the lug nuts.
• 5. The lug nuts and studs should not be lubricated unless advised by the manufacturer. Lubrication can alter torque readings and cause the lug nuts to loosen.
• 6. Use the correct lug nuts for your Mitsubishi model. Using the wrong type can result in improper seating and potential loosening.
• 7. Check lug nuts for wear and damage. Replace any that are stripped, cracked, or otherwise damaged.
• 8. When tightening lug nuts, use the star or crisscross pattern. This will help evenly distribute the pressure and properly seat the wheel.
• 9. If the lug nuts have been removed more than once, consider replacing them to maintain their integrity and proper fit.
• 10. If you have aftermarket wheels, ensure the lug nuts are compatible and follow any instructions provided by the wheel manufacturer.

It is important to follow these safety tips to maintain the safety and performance of your Mitsubishi's wheels.
